HC-SR05 Ultrasonic Distance Sensor
These HC-SR05 ultrasonic distance sensors can measure distances up to 4.5 m.
Add this sensor to your robot project in order for the robot to avoid obstacles when moving!
Specifications
- voltage: 4.5 to 5.5 VDC
- sound frequency: 40 KHz
- measurement resolution: 0.3 cm / 0.01"
- measurement angle: 15 Ā°
- supply current: 10 to 40 mA
- trigger pin format: 10 uS pulse
- connector: 5 pin male
- detection distance: 2-450 cm / 0.79-17.72"
- dimensions: 49 x 22 x 15 mm / 1.93 x 0.87 x 0.59"
CE Doc
Manual
Info Sheets
$1.12
Original: $3.75
-70%HC-SR05 Ultrasonic Distance Sensorā
$3.75
$1.12More Images
HC-SR05 Ultrasonic Distance Sensor
These HC-SR05 ultrasonic distance sensors can measure distances up to 4.5 m.
Add this sensor to your robot project in order for the robot to avoid obstacles when moving!
Specifications
- voltage: 4.5 to 5.5 VDC
- sound frequency: 40 KHz
- measurement resolution: 0.3 cm / 0.01"
- measurement angle: 15 Ā°
- supply current: 10 to 40 mA
- trigger pin format: 10 uS pulse
- connector: 5 pin male
- detection distance: 2-450 cm / 0.79-17.72"
- dimensions: 49 x 22 x 15 mm / 1.93 x 0.87 x 0.59"
CE Doc
Manual
Info Sheets
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
These HC-SR05 ultrasonic distance sensors can measure distances up to 4.5 m.
Add this sensor to your robot project in order for the robot to avoid obstacles when moving!
Specifications
- voltage: 4.5 to 5.5 VDC
- sound frequency: 40 KHz
- measurement resolution: 0.3 cm / 0.01"
- measurement angle: 15 Ā°
- supply current: 10 to 40 mA
- trigger pin format: 10 uS pulse
- connector: 5 pin male
- detection distance: 2-450 cm / 0.79-17.72"
- dimensions: 49 x 22 x 15 mm / 1.93 x 0.87 x 0.59"
